Spring Hinges
AR8280
ARRONE single action spring hinge
Model: AR8280
Item number: 87109011
Finish: SSS Satin Stainless Steel
ARRONE single action spring hinge:
- Material: stainless steel
- Shape: square
- Unit of measure (pack size): sold as 2 spring hinges and 1 unsprung unit
- Door weight: suitable for doors weighing up to 40 kg
- Fixing: 24 x pozidrive countersunk wood screws, supplied with allen key for adjustment of spring tension (with use of locking point)
Material
stainless steel: grade 201 (A1)
Finish
SSS Satin Stainless Steel
Dimensions
102x75x3 mm
Door type
wooden door
Leaf corner
square corners
Drill
4 holes template drilled, countersunk
Fixings
Timber door
Dimension
102x76 mm
Material thickness
3 mm
