Purchase Checklist for HOPPE Products

In order to choose the hardware technically appropriate for the entrance door to your flat or house, any interior door or to choose the right window handle it is important to be aware of the following points and to compare them with the information of the product packaging.
readCache 04/45/8a/7b/page-content-465-458a7bebf2b03d694221a1667c36d9c9.cache :: Cachedatei: 05.03.24 05:33:36 | Seite geändert: 12.10.23 12:59:21 | gültige Cachedatei gefunden

Door hardware

1. For which type of door are the new handles required?

Security hardware for entrance doors

In the case of security hardware for entrance doors, a knob is often fitted to the exterior side of the door, which prevents the opening of an unlocked door. On the interior side an appropriate half-set for interior doors can be fitted.

HOPPE folding box
profile cylinder keyhole (PZ)

Security hardware for entrance doors have this profile cylinder keyhole (PZ). Available with or without cylinder protection (ZA).

Distance between centre of lock follower and centre of profile cylinder hole

Centre of lock follower
92 mm
Centre of profile cylinder hole

HOPPE handle half set with escutcheon (internal)

Handle half sets with escutcheon (internal)
external / internal

The matching entrance and corridor door sets as well as handle sets for interior doors are also available for nearly all of the design.

Entrance and corridor door sets

In the case of entrance and corridor door sets a knob is often fitted to the exterior side of the door. This prevents normal opening of an unlocked door.

profile cylinder keyhole (PZ)

Entrance and corridor door sets have this profile cylinder keyhole (PZ).

Distance between centre of lock follower and centre of profile cylinder hole

Centre of lock follower
72 mm
Centre of profile cylinder hole

HOPPE entrance and corridor door set

external / internal

The matching security hardware and handle sets for interior doors are also available for nearly all of the design.

Handle sets for interior doors

In the case of interior doors you will find the following type of keyholes:

standard keyhole (BB)

standard keyhole (BB)

oval standard keyhole (OB)

oval standard keyhole (OB)

profile cylinder keyhole (PZ)

profile cylinder keyhole (PZ)

Distance between centre of lock follower and centre of profile cylinder hole

Centre of lever hole
72 mm
Centre of keyhole / Centre of profile cylinder hole

HOPPE handle set for interior doors

external / internal

These types of keyholes are appropriate to all common interior door locks.

WC handle sets

If you want to have a WC handle set fitted to your WC doors, you need to know that a WC lock is built in, or can be built in, on these doors:

slotted head / turn button (SK/OL)

external: slotted head
internal: turn button
(SK/OL)

slotted head with red/white indicator / turn button (RW-SK/OL)

external: slotted head with red/white indicator
internal: turn button (RW-SK/OL)

Distance between centre of lever hole and centre of locking turn button

Centre of lever hole
78 mm
Centre of locking turn button

HOPPE WC handle set

external / internal

2. Do you have a “right-hand” or “left-hand” door (according to DIN, German Industrial Standard)?

In cases of entrance doors to houses and flats, a knob is often fitted to the exterior side of the door. This prevents normal opening of the unlocked door.

To be noted

In the case of certain curved handle designs for the interior door side you need to ensure whether you need left-hand or right-hand specification.

Example of a handle design where you need to be sure whether you need a right-hand or left-hand specification:

Handle showing to the right

Handle showing to the right

Handle showing to the left

Handle showing to the left

In order to ascertain which one you want, stand in front of the interior side of your entrance door and check whether the hinges are to the left or the right on the door. In the case of a DIN left-hand door you need a handle pointing to the left and in the case of a DIN right-hand door, a handle pointing to the right.

DIN right-hand door

DIN right

DIN left-hand door

DIN left

3. Which measurements are necessary when buying your Handle of excellence?

1) Spindle size:

Spindle size of door sets

Entrance and corridor door sets:
8 mm or 10 mm
Interior doors / WC doors:
8 mm

Spindle size of turn buttons for Privacy / WC doors

Turn buttons for Privacy / WC doors:
8 mm

2) Distance between centre of lock follower and centre of keyhole:

Distance between centre of lock follower and centre of keyhole

Entrance and corridor doors:
72 mm or 92 mm
Interior doors:
72 mm
WC doors:
78 mm

3) Door thickness:

Door thickness

The door thickness affects the length of the spindle and screws required, so it’s important the exact door thickness is measured.
The packaging shows the suitable door thickness of the handle set.

In order to be able to choose the handles which are right for your doors, it’s important to compare the information from the check-list with the details on the packaging.

Appropriate mounting items as well as detailed assembly instructions can be found with every HOPPE product.

Window handles

4. Are you able to replace your window handles easily?

It’s easy to replace your present window handles with new ones, for example lockable window handles like Secu100® + Secustik® or Secustik®.

Turn the old handle to the opening position (horizontal). Then lift the cover cap slightly and rotate it by 90 °. Loosen the screw and remove the old handle. Now you can fit the new handle.

Replacing a window handle
Window handle spindle length

Spindle length
The window profile affects the length of the spindle. Please measure the spindle length of the old window handle and compare it with the information on the packaging.

Window handle spindle size

Spindle size
Windows E = 7 mm
