Cam-action door closer
AR6509
ARRONE overhead door closing device
Model: AR6509
Item number: 50008444
Finish: Silver Enamel
ARRONE overhead door closing device:
- Power size: 2 to 5 adjustable by spring tension
- Function: Closing, latching, backcheck, delayed action
- Cover: Box cover
- Maximum door width: 1,250 mm
- Maximum door weight: 100 kg
- Arm application: door mount pull, transom mount push
- Successfully type tested for conformity to all the requirements of BS EN 1154:1997
- Door mount pull side: 4 | 8 | 5/2 | 1* | 1 | 3
- Transom mount push side: 3 | 8 | 5/2 | 1* | 1 | 3 - Included in a successful fire test to BS EN 1634 Part 1. Assessed for use on 30, 60 and 120 minutes timber fire doors.
- CE Marked: AD5285, UKCA Marked: AD7690
- Certifire approved: CF5430, CE DOP: HUK0066, UKCA DOP: HUK0066
Arm Application
door mount pull, transom mount push
Arm type
Surface slide arm
Mechanism dimensions and fixing centres
256.5x60x48mm; centres 112x45mm
Finish of the cover
Silver Enamel
Fixings
Timber door
Mechanism function
Backcheck, delayed action, spring adjustment, closing/latching speed
Opening Angle
max. 180° opening
Slide track application
door mount pull, transom mount push
Product type
none
Rose shape
None available
Version
none
Finish
Silver Enamel
Commodity Class
AR6000 Door Closer
Maximum door width
1250 mm
Maximum door weight
100 kg
Mechanism type
cam action
Power size
2 to 5
Shape
Box
Door type
wooden door
