Cam-action door closer
AR6309
ARRONE overhead door closing device
Model: AR6309
Item number: 50008341
Finish: Silver Enamel
ARRONE overhead door closing device:
- Fixed power size 3
- Function: Closing, latching
- Cover: no cover
- Maximum door width: 950 mm
- Maximum door weight: 60 kg
- Arm application: door mount pull, transom mount push
- Successfully type tested for conformity to all the requirements of BS EN 1154:1997
- Door mount pull side: 4 | 8 | 3 | 1* | 1 | 3
- Transom mount push side: 3 | 8 | 3 | 1* | 1 | 3 - Included in a successful fire test to BS EN 1634 Part 1. Assessed for use on 30, 60 and 120 minutes timber fire doors.
- CE Marked: AD5276
- Certifire approved: CF5430; DOP: HUK0064
Arm Application
door mount pull, transom mount push
Arm type
Surface slide arm
Mechanism dimensions and fixing centres
205x56x43mm; centres 80x41mm
Finish of the cover
Silver Enamel
Fixings
Timber door
Mechanism function
Fixed power, closing/latching speed
Opening Angle
max. 180° opening
Slide track application
door mount pull, transom mount push
Product type
none
Rose shape
None available
Version
none
Finish
Silver Enamel
Commodity Class
Door closing devices surface overhead
Maximum door width
950 mm
Maximum door weight
60 kg
Mechanism type
cam action
Power size
3
Shape
Trim Plate
Door type
wooden door
