HOPPE Quick-FitPlus

With Quick-FitPlus, not only door handles, but also the corresponding handle roses and escutcheons can be installed quickly and easily. Both standard roses and flat roses can be installed in just a few simple steps without screws – self-adhesive or pluggable.
HOPPE – Handle of excellence.
HOPPE Quick-FitPlus – Quick and easy fitting of door handles and roses
readCache 18/b0/aa/3f/b6/86/page-content-2775-b0aa3fb686445726b2c605629759afcd.cache :: Cachedatei: 2024-05-02 13:20:09 -- 23.05.24 13:27:25 | Seite geändert: 2024-05-02 13:20:09 -- 02.05.24 15:20:09 | gültige Cachedatei gefunden

HOPPE Quick-FitPlus – Less is More

HOPPE Quick-FitPlus is the logical further development of the tried and tested HOPPE Quick-Fit connection. With this technology, it is not just the door handles which can be fitted easily and without the need for screws, but also the matching handle roses and escutcheons.

Non-screw fitting

Simple Installation

With HOPPE Quick-FitPlus both standard roses and the almost flush flat roses are installed in just a few steps:

  • Standard or flat roses with through-going supporting lugs are simply put together on the prepared door.
  • Self-adhesive flat roses are precisely aligned and glued on using a square spindle or installation key.
  • Both versions are fitted completely without screw connection
HOPPE Quick-FitPlus handle set with supporting lugs
HOPPE Quick-FitPlus handle set with supporting lugs
HOPPE Quick-FitPlus handle set with self adhesive handle rose and escutcheon
HOPPE Quick-FitPlus handle set with self-adhesive handle rose and escutcheon

Two fitting versions are possible with the HOPPE Quick-FitPlus handle sets:

With Supporting Lugs

  • Door handles with HOPPE Quick-Fit connection
  • Handle roses with supporting lugs
  • Escutcheons with supporting lugs or self-adhesive as flat roses
  • Handle sets for commercial applications, tested to BS EN 1906 (category of use: grade 3)
  • Two guide holes (Ø 7.5 mm) are required to accommodate the supporting lugs

Self-Adhesive

  • Door handles with HOPPE Quick-Fit connection
  • Self-adhesive handle roses
  • Self-adhesive escutcheons (if needed)
  • No special door preparation required

Fitting

The handle roses with through-going supporting lugs and the door handles are simply fitted together and escutcheons with through-going supporting lugs added if necessary, with the whole set able to be installed without the need for screws.

Put the handle roses together
Put the handle roses together
Put the door handles together
Put the door handles together
If necessary, put the escutcheons together – and fitting is complete!
If necessary, put the escutcheons
together – and fitting is complete!

YouTube

By loading the video, you accept YouTube's privacy policy.
Learn more

Load video

YouTube

By loading the video, you accept YouTube's privacy policy.
Learn more

Load video

European patents EP 1 683 933 and EP 3 202 999
HOPPE Quick-Fit connection

View HOPPE Quick-FitPlus door handles in the product catalogue

Go to the product catalogue
